> >>UNIKA BLUETOOTH STEREO DI BOX
Bluetooth Stereo DI Box View larger

UNIKA

UNIKA BLUETOOTH STEREO DI BOX

UNIDI-BT

UNI-DI BT

New product

UNIKA BLUETOOTH STEREO DI BOX

More details

Balcatta: 0
Geebung: 0

The DI-BT Box is a high resolution stereo direct box designed to wirelessly pair with Bluetooth® enabled devices, once it is powered up, it will automatically be listed as an available device on your Bluetooth enabled computer, tablet or smart phone. A professional Hi-Z direct input is also equipped, this is most commonly used with guitar pickups or keyboards, it also can be fed either from a line-level output from the head (pad set to -20dB) or from the amplifier po wer output.

A stereo pair of balanced XLR audio outputs with adjustable level control then feeds the signal to a microphone preamplifier, PA system, mixing console or even a powered speaker. The transferred Bluetooth Streaming audio can be monitored on headphones through the 3.5mm analog output jack to check signal quality and level before connecting to a sound system. Two isolated output transformers are equipped to eliminate any hum or buzz caused by ground loops. To further reduce susceptibility to noise, this is augmented with a ground lift switch that lifts pin 1 on both XLR jacks.

Features

  • High impedance direct input for electronic musical instrument signal feed.
  • USB type-B Mini port, connect to computer for 5V supply.
  • 3.5mm TRS headphone output for audio level monitoring.
  • Front panel Level control used for stereo output along with headphone volume adjustment.
  • The direct input audio signal will mix to the Bluetooth stereo audio signal at the output stage.
  • Selectable 3 steps attenuator for Hi-Z direct input.
  • Accept power from 9V battery or 5V from computer USB and +20V to +48V Phantom power.
  • 2 channel XLR Balanced Low-Z output with isolation transformer.
  • Colour Black & Blue
  • Dimensions (H x W x D) 158 x 112 x 46 mm
  • Material 14 gauge steel cabinet & chassis
  • Warranty 3 Years
  • Weight 1.2 kg
